Imaging Equipment

Digital Video Camera

KEL's connectors for micro coaxial cables that we have pursued miniaturization and high speed transmission realize state-of-the-art connection technology which is needed in imaging equipment.

Board to Board Connectors
Series name Catalog Mating Matrix Product Table Category Pitch No. of contacts

DU Series
pdf pdf pdf 0.4mm Pitch Floating Connector 0.4mm 80, 110, 120, 200

DT Series
pdf pdf pdf 0.5mm Pitch Floating Connector for High-Speed Transmission 0.5mm 30, 40, 60, 80, 100, 140, 240

DY Series
pdf pdf pdf 0.5mm Pitch Floating Connector 0.5mm 30, 40, 50, 60, 80, 100, 120, 140
Board to Cable Connectors
Series name Catalog Mating Matrix Product Table Category Pitch No. of contacts

XSL Series
pdf pdf pdf 0.25mm Pitch Connector for Micro Coaxial Cable (#42 AWG, #44 AWG, #46 AWG) 0.25mm 48

XSLS Series
pdf pdf pdf 0.25mm Pitch Connector for Micro Coaxial Cable / Stacking Type (#42 AWG, #44 AWG, #46 AWG) 0.25mm 30, 40

USL Series
pdf pdf pdf 0.4mm Pitch I.D.C. Connector for Micro Coaxial Cable (#42 AWG) 0.4mm 20, 30, 40

USLS Series
pdf pdf pdf 0.4mm Pitch I.D.C. Connector for Micro Coaxial Cable / Stacking type (#42 AWG) 0.4mm 20, 30, 40

USLS21 Series
pdf pdf pdf 0.4mm Pitch Connector for Micro Coaxial Cable / Soldered Connection / Stacking Type (#42 AWG, #44 AWG, #46 AWG) 0.4mm 34

SSL Series
pdf pdf pdf 0.5mm Pitch 2 Piece Connector for Micro Coaxial Cable (#40 AWG) 0.5mm 10, 20, 30, 40

TMC Series
pdf pdf pdf 0.5mm Pitch High Speed Transmission Connector for Micro Coaxial Cable 0.5mm 51
