Automotive Equipment

EV

With focusing on miniature floating connectors, we have been developing new and original products suitable for automotive equipment.

EV


Related Applications

Board to Board Connectors
Series name Catalog Mating Matrix Product Table Category Pitch No. of contacts

DU Series
pdf pdf pdf 0.4mm Pitch Floating Connector 0.4mm 80, 110, 120, 200

DT Series
pdf pdf pdf 0.5mm Pitch Floating Connector for High-Speed Transmission 0.5mm 30, 40, 60, 80, 100, 140, 240

DY Series
pdf pdf pdf 0.5mm Pitch Floating Connector 0.5mm 30, 40, 50, 60, 80, 100, 120, 140

8900MS Series
pdf pdf pdf 1.27mm Pitch 2 Piece Low Profile SMT Connector 1.27mm 20, 30, 40, 50, 60, 80, 100, 120

8900 Series
pdf pdf pdf 1.27mm Pitch 2 Piece Low Profile Connector 1.27mm 20, 30, 40, 50, 60, 80, 100, 120

8903N-FS Series
pdf pdf pdf 1.27mm Pitch 2 Piece Low Profile Connector / Flexible Stack Type 1.27mm 40, 50, 60, 68, 80, 100

8800 Series
pdf pdf pdf 1.27mm Pitch 2 Piece Connector 1.27mm 20, 26, 30, 32, 34, 40, 50, 52, 60, 68, 80, 100

8832E-FS Series
pdf pdf pdf 1.27mm Pitch 2 Piece Connector / Flexible Stack Height Type 1.27mm 20, 30, 40, 50, 60, 80, 100

8806/8807 Series
pdf pdf pdf 1.27mm Pitch 2 piece Connector / Multi-Pin Connector 1.27mm 120, 140, 160, 180, 200
Board to Cable Connectors
Series name Catalog Mating Matrix Product Table Category Pitch No. of contacts

XSL Series
pdf pdf pdf 0.25mm Pitch Connector for Micro Coaxial Cable (#42 AWG, #44 AWG, #46 AWG) 0.25mm 48

XSLS Series
pdf pdf pdf 0.25mm Pitch Connector for Micro Coaxial Cable / Stacking Type (#42 AWG, #44 AWG, #46 AWG) 0.25mm 30, 40

USL Series
pdf pdf pdf 0.4mm Pitch I.D.C. Connector for Micro Coaxial Cable (#42 AWG) 0.4mm 20, 30, 40

USLS Series
pdf pdf pdf 0.4mm Pitch I.D.C. Connector for Micro Coaxial Cable / Stacking type (#42 AWG) 0.4mm 20, 30, 40

USLS21 Series
pdf pdf pdf 0.4mm Pitch Connector for Micro Coaxial Cable / Soldered Connection / Stacking Type (#42 AWG, #44 AWG, #46 AWG) 0.4mm 34

SSL Series
pdf pdf pdf 0.5mm Pitch 2 Piece Connector for Micro Coaxial Cable (#40 AWG) 0.5mm 10, 20, 30, 40

8929E Series
pdf pdf pdf 1.27mm Pitch Connector for Discrete Cable / Crimp Type 1.27mm 30, 40, 50, 60, 68

8925E Series
pdf pdf pdf 1.27mm Pitch Low Profile Connectors for 0.635mm Pitch Flat Cable 1.27mm 20, 30, 40, 50, 60, 68, 80, 100

8825E Series
pdf pdf pdf 1.27mm Pitch Connector for 0.635mm Pitch Flat Cable 1.27mm 20, 26, 30, 32, 34, 36, 40, 50, 52, 60, 68, 80, 100

8822E/8822 Series
pdf pdf pdf 1.27mm Pitch Connector for 1.27mm Pitch Flat Cable 1.27mm 20, 26, 30, 32, 34, 36, 40, 50, 52, 60, 68, 80, 100
Socket & Battery Connectors
Series name Catalog Mating Matrix Product Table Category Pitch No. of contacts

ISC Series
pdf - pdf ISO Card Connector / Landing Contact Type 2.54mm 8
