Infrastructure Equipment

Power Plant

The quality of KEL's racks and industrial connectors keeps responding to high reliability and environmental resistance needed in infrastructure equipment.

Power Plant


Related Applications

Board to Board Connectors
Series name Catalog Mating Matrix Product Table Category Pitch No. of contacts

DT Series
pdf pdf pdf 0.5mm Pitch Floating Connector for High-Speed Transmission 0.5mm 30, 40, 60, 80, 100, 140, 240

DY Series
pdf pdf pdf 0.5mm Pitch Floating Connector 0.5mm 30, 40, 50, 60, 80, 100, 120, 140

8600 Series
pdf pdf pdf 0.635mm Pitch 2 piece Connector 0.635mm 52, 60, 120, 140, 160, 200

8602E Series
pdf pdf pdf 0.635mm Pitch 2 piece Connector / Eject-Lock Type 0.635mm 60, 140, 160

8900MS Series
pdf pdf pdf 1.27mm Pitch 2 Piece Low Profile SMT Connector 1.27mm 20, 30, 40, 50, 60, 80, 100, 120

8900 Series
pdf pdf pdf 1.27mm Pitch 2 Piece Low Profile Connector 1.27mm 20, 30, 40, 50, 60, 80, 100, 120

8903N-FS Series
pdf pdf pdf 1.27mm Pitch 2 Piece Low Profile Connector / Flexible Stack Type 1.27mm 40, 50, 60, 68, 80, 100

8800 Series
pdf pdf pdf 1.27mm Pitch 2 Piece Connector 1.27mm 20, 26, 30, 32, 34, 40, 50, 52, 60, 68, 80, 100

8832E-FS Series
pdf pdf pdf 1.27mm Pitch 2 Piece Connector / Flexible Stack Height Type 1.27mm 20, 30, 40, 50, 60, 80, 100

8806/8807 Series
pdf pdf pdf 1.27mm Pitch 2 piece Connector / Multi-Pin Connector 1.27mm 120, 140, 160, 180, 200

4630 Series
- - pdf 2.54mm Pitch Card Edge Connector 2.54mm 44, 48, 56, 60, 72, 88, 100

4640 Series
pdf - pdf 2.54mm Pitch Card Edge Connector 2.54mm 44, 48, 56, 60, 62, 72, 86, 88, 100

936 Series
- - pdf 2.54mm Pitch Card Edge Connector 2.54mm 100, 120

937 Series
- - pdf 2.54mm Pitch Card Edge Connector 2.54mm 62, 98

4810 Series
- - pdf 3.175mm Pitch Card Edge Connector 3.175mm 40, 60, 80, 100

4820 Series
pdf - pdf 3.18 (3.175)mm Pitch Card Edge Connector 3.175mm 40, 60, 80, 100

1258N Series
pdf - pdf 3.96mm Pitch Card Edge Connector 3.96mm 44, 56, 60, 72, 86, 88

1168 Series
pdf - pdf 3.97mm Pitch Card Edge Connector 3.97mm 20, 28, 30, 36, 44, 56

1156 Series
- - pdf 4mm Pitch Card Edge Connector 4mm 20, 28, 36, 44, 56, 72, 88

1150N Series
- - pdf 4mm Pitch Card Edge Connector 4mm 20, 28, 36, 44, 56

3205/3305 Series
- - pdf 4mm Pitch Card Edge Connector 4mm 10, 14, 18, 22

3250 Series
- - pdf 4mm Pitch Card Edge Connector 4mm 10, 14, 18, 22
Board to Cable Connectors
Series name Catalog Mating Matrix Product Table Category Pitch No. of contacts

FTC Series
- pdf pdf 5.08mm Pitch Drawer Connector / Capable of Crimping Two Cables 5.08mm 12

8929E Series
pdf pdf pdf 1.27mm Pitch Connector for Discrete Cable / Crimp Type 1.27mm 30, 40, 50, 60, 68

8825E Series
pdf pdf pdf 1.27mm Pitch Connector for 0.635mm Pitch Flat Cable 1.27mm 20, 26, 30, 32, 34, 36, 40, 50, 52, 60, 68, 80, 100

8822E/8822 Series
pdf pdf pdf 1.27mm Pitch Connector for 1.27mm Pitch Flat Cable 1.27mm 20, 26, 30, 32, 34, 36, 40, 50, 52, 60, 68, 80, 100
